OS NINO+ DVB-S2 + DVB-T2/C
Product Code:
01-08-0009
  • Manufacturer:
    EDISION
  • Barcode:
    5200378400128
  • Pieces per package:
    10
  • Pieces per pallet:
    600
  • Net weight:
    0.55 kg
  • Gross weight:
    0.71 kg
  • Dimensions per package:
    50x29x18
  • Uploaded on:
    19-01-2018

The OS NINO+ DVB-S2 + DVB-T2/C Hybrid E2 LINUX combo Full High Definition receiver with H.265/HEVC decoding support, is the new member in the E2 LINUX series receivers from EDISION. It combines all the updated technical features to provide you with enjoyable use of all its advanced specifications, in an incredibly compact size!. Some of its features include: E2 Linux operational system, H.265/HEVC decoding, BROADCOM MIPS Dual Core @ 742MHz processor, 512MB SLC NAND Flash / 512MB DDR3 memory, WiFi & Bluetooth on Board, Full Media Player along with the ergonomical and multifunctional 2-in- IR remote control EDI-RCU OS, for programming and controlling up to five (5) TV functions! ! All these, plus the all-around EDISION quality and support included!

Technical features:
- Type: Combo DVB-S2 + DVB-T2/C digital satellite receiver E2 Linux Full HD
- 1 x Tuner DVB-S2
- 1 x Tuner DVB-T2/C
- Linux operational system
- Processor: Mips Broadcom 742 MHz Dual-Core
- Speed Up to speed 742MHz and up to 2000 DMIPS
- 512MB SLC NAND Flash / 512MB of DDR3 memory
- Video Resolution: 1080p, 1080i, 780p, 720p, 576p, 576i, 480p, 480i
- Full Media Player
- Web Browser and supports HbbTV
- Free Internet Streaming TV and Radio
- WiFi Connection: embedded
- Bluetooth: embedded 2.1/3.0/4.0
- Decoding: H.265/HEVC decoding support (covered by patents listed at patentlist.hevcadvance.com).
- Unlimited channel memory
- Hyper-sensitive tyner for receiving even the weak-signal channels.
- 1 x Smartcard reader
- 10/100 Mbps Ethernet interface
- 2 x USB2.0 PVR Ready ports
- 1 x HDMI 1.4a Connection
- 1 x jack to RS232
- 1 x jack to IR
- 1 x S/PDIF
- Channel switch in less than 1 second.
- Extensive ΕPG and programmed viewing via EPG
- Expandable Add-Ons & Plug-Ins
- Supports Bouquet list
- Multilingual OSD, Skin - support
- Channel search: Fully automatic/Manual
- Time Shift function and Multi Timers
- Supports Teletext & and OSD and VBI subtitles
- Compatible with DiSEqC 1.0, 1,1 ,1.2 and 1.3 (USALS)
- Power consumption less than 0.5 Watt, in low-power stand-by mode.

Front Panel:
- Display: LED (Standby, Recording)
- 1 x Smartcard slot

Side Panel:
- 2 x USB 2.0

Back Panel:
- Input Sat-IF: 1x F-type
- Input RF: 1x IEC-type
- Connection TV: 1x HDMI
- Video output (digital): 1x HDMI
- Audio output (analog): Standard optical (S/PDIF)
- 1 x Ethernet plug
- 1 x jack to RS232
- 1 x jack to IR
- 1 x DC in (for the external PSU)

Package contains:
- EDISION EDI-RCU OS 2-in-1 remote control
- External PSU 12v
- Jack to RS232 cable
- Start Guide EN/DE/GR
- 2 x "ΑΑΑ" batteries

General:
- Dimensions: (W x H x D): 145x35x120 (mm)
- Weight: 0,5 kg
- Color: black
- Warranty: 2 years
