TVIP10055B Compact Network Camera WLAN
Product Code:
20-07-0007
  • Manufacturer:
    ABUS
  • Barcode:
    4003318598746
  • Pieces per package:
    1
  • Net weight:
    0.35 kg
  • Gross weight:
    0.63 kg
  • Uploaded on:
    01-11-2017
  • The product was removed:
    02-12-2022

Product description:

ABUS TVIP10055B WLAN camera is made for simple indoor surveillance tasks. It offers: Simple initial operation using ABUS DDNS server, Uncomplicated live cast and playback via app, VGA resolution: 640 x 480 @ 25 fps, WLAN interface 802.11b/g/n, WPS button for easy setup of the WLAN connection, easy initialization, no need for IP networking knowledge, Optimal price/performance ratio. A web browser or a free app (''Life View'') can be used to operate the camera and access live images. An installation example is to see who is coming or who is at the door without extras, without elaborate configuration. A basic surveillance device with real-time images, which is often sufficient for private use. The TVIP10055B LAN camera can be easily installed and operated by anyone, as the Setup of the camera parameters is easy through the ABUS DDNS Server, all you need to do is connect the camera with the router using a network cable. No need to take note of and find out IP addresses. Integration in a WLAN network is possible with a press of the WPS button and the connection is encrypted.

Technical features:

- Camera type: Color
- Focal length: 1,7 mm
- Image sensor: 1/4'' progressive scan CMOS-sensor
- Minimum illumination (color): 0.8 lux
- Frame rate: 25 fps
- White balance: AWB
- Backlight compensation: BLC
- Digital zoom: 10
- Horizontal angle of view: 67 °
- Max. resolution @ frame rate: 640 x 480 @ 25 fps
- Resolution modes: 640 x 480, 320 x 240, 160 x 120 pixel
- Video compression: MJPEG
- Pixels (effective): 640 x 480 pixel
- Pixels (total): 640 x 480 pixel
- Microphone: Yes
- Network camera protocols: TCP/IP, DHCP, PPPoE, ARP, ICMP, DNS, NTP, UPnP, HTTP, UDP
- Video network bandwidth: 6 MBit/s
- WLAN network access: 802.11b/g/n
- Encryption: WEP/WPA/WPA2
- LAN network access: RJ45
- Connections: 1 x RJ45, 1 x DC
- IP protection class: 34
- Operating temperature: 0 °C ~ 40 °C
- Max. humidity: 80 %
- DC voltage supply: 5 V
- Power consumption: 260 mA
- Dimensions LxWxH: 32.4 x63.1x77.1 mm
- Certifications: CE, RoHS, Reach
- Warranty: 2 years

Scope of delivery:

1 x Compact Network Camera WLAN
1 x 5 VDC power supply unit
1 x 1 m network cable
1 x Wall mount incl. fixing screws
1 x Installation CD
