Product description:
Line amplifier with high output. Aesthetic design and low power consumption. With 4+1 signal outputs, F-type.
Technical features:
- Frequency range: MHz 47-862
- Gain Outputs: db 4X 16 (OUT), 1X 11 (TV).
- Gain adjustment: db 12.
- Noise figure: db 5.
- Output level DIN45004B: db΅V 102
- Mains power supply: 207-253 v
- Max temperature: 45 C
- Protection index IP 20
- AC Power consumption: W 2
- Dimensions (Wid x Hei x Dep) (mm): 145 x 60 x 35
